3AT2 Half-Wave High Voltage 30 KV Diode Rectifier Toshiba Electronic Vacuum Tube
This is an original Toshiba 3AT2 Half-Wave Vacuum Rectifier electronic tube. Applications for this tube is for high-voltage low-current half-wave rectifier applications, usually in television receivers or HV, HF equipments. This is a collectable vintage special vacuum tube. Useful for those antique radio or television restoration projects, high voltage project or to set up a private vacuum tube museum. It is a NOS tube - new old stock, unused, boxed, excellent condition.
Features: • 3AT2 Half-Wave Vacuum Rectifier Tube • MFG: Toshiba • Quality Made in Japan • Pulsed Rectifier, HV, HF Rectifier • Heater: 3.15 V, 0.22 A - 1.5 pF • Plate: 30,000 Vmax, 88 mAmax - 1.7 mAavg • Base: 12-pin all glass duodecar Notes: • NOS - [New Old Stock] tube • Original box • Unused • Price: $15 • One available • S/H included within continental US |
3AT2 Duodecar 12-pin Electronic Vacuum Tube Electrode Connections
PIN # | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | CAP |
Electrode | F C IS | F C IS | - | - | F C IS | F C IS | - | F | F C IS | - | - | F | Anode |
C=Cathode, F=Filament, IS=Int Shield
• Only one item available unless otherwise indicated • Click the credit card pictures left to order • • E-Mails always answered unless return e-mail is blocked |
