4LJ8 Medium-Mu Triode Sharp-Cutoff Pentode Oscillator Sarkes Tarzian Vacuum Tube

This is an original Sarkes Tarzian 4LJ8 Medium-Mu Triode, Sharp-Cutoff Pentode electronic tube. The 4LJ8 was developed for oscillator and mixer color television applications. The pentode part works well as an IF, video, AGC amplifier. The triode side works well for AM/FM and VHF oscillator circuits. Excellent for those antique radio restoration projects, experimentation, circuit research or to set up a private vacuum tube museum. It is NOS tube - New Old Stock, unused, boxed in good condition. First come first serve. Only one available!
4LJ8 Medium-Mu Triode Sharp-Cutoff Pentode Oscillator Sarkes Tarzian Vacuum Tube [13 KB]
HARD TO FIND ORIGINAL HISTORICAL TUBE

Features:

4LJ8 Medium-Mu Triode, Sharp-Cutoff Pentode
• MFG: Sarkes Tarzian • Quality Made in USA
• Oscillator, Nixer, IF, Video, RF/AF Amplifier
• Heater: 4.3 V, 0.6 A
• Plate: 280 Vmax, 13 mAmax, 2 Wmax - Triode Class A
• Plate: 280 Vmax, 12 mAmax, 2 Wmax - Pentode Class A
• Base: 9-pin noval, all glass - Collectible

Notes:

NOS - New Old Stock tube • Original box
• Unused • Price: $30 • One available
S/H included within continental US
4LJ8 Noval 9-Pin Miniature All Glass Electronic Vacuum Tube Electrode Connections
PIN # 1 2 3 4 5 6 7 8 9
Electrode Grid 1 T Anode T Cathode Heater Heater Anode P Grid 2 Cath G3 Grid 1 P
F=, IC=Internal Connection
